Dukane P220 - System Inputs;Outputs Signal Pinouts on the J5 Connector

18
SECTION 3 | INSTALLATION
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Note





hp://update.dukane.com
System Inputs/Outputs Signal Pinouts on the J5 Connector
Pin
Color
Description
J5-1
BLK/RED
+22VDC CURRENT LIMITED POWER SUPPLY (500mA MAX)
J5-2
RED/BLK
+22VDC RETURN (CHASSIS GROUND)
J5-3
BLK/WHT
REMOTE SETUP BIT 0 INPUT
J5-4
WHT/BLK
REMOTE SETUP BIT 1 INPUT
J5-5
BLK/GRN
REMOTE SETUP BIT 2 INPUT
J5-6
GRN/BLK
REMOTE SETUP BIT 3 INPUT
J5-7
BLK/BLU
REMOTE SETUP BIT 4 INPUT
J5-8
BLU/BLK
SYSTEM LATCH RESET INPUT
J5-9
BLK/YEL
AUTOMATION (EOC) STOP INPUT
J5-10
YEL/BLK
FRONT PANEL LOCKOUT INPUT
J5-11
BLK/BRN
ISOLATED INPUT COMMON
J5-12
BRN/BLK
ULTRASOUND ACTIVATION / CYCLE START INPUT
J5-13
BLK/ORN
ISOLATED ULTRASOUND INPUT COMMON
J5-14
ORN/BLK
E-STOP STATUS OUTPUT
J5-15
RED/WHT
PROGRAMMABLE STATUS OUTPUT J5 PIN 15 (HOLD)
J5-16
WHT/RED
PROGRAMMABLE STATUS OUTPUT J5 PIN 16 (TRIGGER)
J5-17
RED/GRN
PROGRAMMABLE STATUS OUTPUT J5 PIN 17 (OVER TEMP)
J5-18
GRN/RED
PROGRAMMABLE STATUS OUTPUT J5 PIN 18 (IN-CYCLE)
J5-19
RED/BLU
ULTRASOUND STATUS OUTPUT
J5-20
BLU/RED
ANY FAULT STATUS OUTPUT
J5-21
RED/YEL
OVERLOAD STATUS OUTPUT
J5-22
YEL/RED
BAD PART STATUS OUTPUT
J5-23
RED/BRN
GOOD PART STATUS OUTPUT
J5-24
BRN/RED
READY STATUS OUTPUT
J5-25
RED/ORN
TOP OF STROKE STATUS OUTPUT
J5-26
ORN/RED
ISOLATED OUTPUT COMMON (SOURCING OR SINKING INPUTS)
Table 3-5
