SECTION 6 | SPECIFICATIONS
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Table 7-3 P220 System Number Guide
Example System
Number: 2026.2H.C3-04.MS
Description: A 20 kHz 2600 Watt P220™ Horizontal generator with a 220/240 VAC line cord and PROFINET communications module, a medium-sized P220 dual
pressure pneumatic press on a Standard Round Column.
P220™ System Number Guide
20
Nominal U/S
Frequency
15 = 15 kHz
20 = 20 kHz
30 = 30 kHz
35 = 35 kHz
40 = 40 kHz
50 = 50 kHz
70 = 70 kHz*
Power Level
50 = 5000 W
36 = 3600 W
26 = 2600 W
20 = 2000 W
18 = 1800 W
12 = 1200 W
09 = 900 W*
07 = 700 W*
06 = 600 W
Generator AC Line
1 = 110/120 VAC
2 = 220/240 VAC
4 = 480V (Three-Phase)
E = 220/240 VAC (Europe)
N = 220/240 VAC (India)
C = 220/240 VAC (China)
26
Generator Type
H = Horizontal
V = Vertical
.
2 H
. .04 XXX M S XX##
Press Type
04 = Pneumatic, Standard (Dual Pressure)
05 = Pneumatic with Distance
06 = Pneumatic with Distance and Load Cell
10 = Pneumatic with Load Cell
Press Options
Blank = No Options
3 = 3” Air Cylinder
Press Size
H = Medium (30, 35, 40, and 50 kHz)
L = Large (15 kHz & Super 20)
M = Medium (20 kHz)
Support Options
LS = Less Base with Standard Round Column
LR = Less Base with Rigid Column
L4 = Less Base with 4 ft. Round Column
L5 = Less Base with 5 ft. Round Column
L6 = Less Base with 6 ft. Round Column
S = Standard Round Column (see NOTE below)
R = Rigid Column
T = Thruster Only
4 = 4 ft. Round Column (see NOTE below)
5 = 5 ft. Round Column (see NOTE below)
6 = 6 ft. Round Column (see NOTE below)
C = Round Column Ready (Less Base, Flange
and Column)
Customization
Blank = No Customization
XX## = Customization Code
- -
C3
Generator Communications
Options
C0 = None
C2 = iQLinQ™ only, Ethernet/IP
C3 = iQLinQ™ only, PROFINET
C4 = iQLinQ™ only, CC-Link
C5 = iQLinQ™ only, POWERLINK
C6 = iQLinQ™ only, EtherCAT
E0 = iQ Explorer 3 only
E2 = iQ Explorer 3 and iQLinQ™, Ethernet/IP
E3 = iQ Explorer 3 and iQLinQ™, PROFINET
E4 = iQ Explorer 3 and iQLinQ™, CC-Link
E5 = iQ Explorer 3 and iQLinQ™, POWERLINK
E6 = iQ Explorer 3 and iQLinQ™, EtherCAT
NOTE:
If HMI kit (438-1094) is being purchased with
the system, a rigid column must be specified
(code LR or R).
SEE NEXT PAGE FOR REVISION HISTORY →
Note: Not all combinations are possible or available.
* = Consult Marketing
