SECTION 6 | SPECIFICATIONS
41
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Example 1: Part Number: 20HS360-2Y-C2-P-N0 Description: 20 kHz horizontal bench generator, 3600 W, 200-240 VAC, for P220 press with Ethernet/IP support, and no option card support. Example 2: Part Number: 30HS120-UY-C2-P-N0-AA01
Description: 30 kHz horizontal bench generator, 1200 W, 100-240 VAC, for P220 press with Ethernet/IP support, no option card support, with customization 01 for customer AA.
P220 Generator Number Guide
20
Nominal U/S
Frequency
15 = 15 kHz 20 = 20 kHz 25 = 25 kHz 30 = 30 kHz 35 = 35 kHz 40 = 40 kHz 50 = 50 kHz 70 = 70 kHz
Power Level
500 = 5000 W 360 = 3600 W 260 = 2600 W 120 = 1200 W 090 = 900 W 070 = 700 W 060 = 600 W
AC Line Input
2 = 200-240 VAC (1800 W to 5000 W)
Standard PFC for 2600W and below. High power PFC for above 2600W.
4 = 480 VAC Three-Phase U = 100-240 VAC universal voltage input
(1200W and below)
360
Front Panel
Y = LCD Display
Communications Bus
C0 = None C2 = iQLinQ™ only, Ethernet/IP C3 = iQLinQ™ only, PROFINET C4 = iQLinQ™ only, CC-Link C5 = iQLinQ™ only, POWERLINK C6 = iQLinQ™ only, EtherCAT E0 = iQ Explorer 3 only E2 = iQ Explorer 3 and iQLinQ™, Ethernet/IP E3 = iQ Explorer 3 and iQLinQ™, PROFINET E4 = iQ Explorer 3 and iQLinQ™, CC-Link E5 = iQ Explorer 3 and iQLinQ™, POWERLINK E6 = iQ Explorer 3 and iQLinQ™, EtherCAT
2
Y
C2
P
-
Press Type
P = P215, P220, P230
Note: Not all combinations are possible or available.
Chassis
Orientation
HS = Horizontal VS = Vertical
HS
-
-
-XX##
Customization
Blank = No Customization XX = Customer Abbreviation ## = Customization Code
Table 7-4 P220 Generator Number Guide
