SECTION 6 | SPECIFICATIONS
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Table 7-5 P220 Thruster Number Guide
Example 1:
Part Number: P220TMED
Description: P220 thruster with 2.5” air cylinder and distance encoder.
Example 2:
Part Number: P220TMHN-CEN01
Description: P220 thruster with 3.0” air cylinder and customization code “EN01”.
Example 3:
Part Number: P215TMEF
Description: P215 thruster with 3” air cylinder and force sensor.
P220™ Thruster Number Guide
20
Press Type
15 = 15 and Super 20 kHz
20 = 20 kHz
30 = 30, 35, 40, and 50 kHz
Press Component
T = Thruster
Press Cylinder
ME = 20 kHz Standard (2.5” Bore)
MH = 20 kHz High Force (3” Bore)
LA = 15 kHz Standard (3” Bore)
ML = 30 kHz and Higher Standard (1.5” Bore)
T
ME
D
Cxxxx
Standard Options
N = None (contains Spring Trigger Sensor)
D = Distance (contains Encoder and Spring Trigger Sensor)
F = Force (contains Load Cell)
B = Distance and Force (contains Encoder and Load Cell)
Customization
Cxxxx = Custom with Code ####
-
P2
Family Identifier
P2 = P2 Pneumatic
