Dukane P220 - Position Indicators

SECTION 5 | CONTROLS AND INDICATORS
33
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Figure 5-5
Posion Indicators




MECHANICAL
STOP LOCK
SETSCREW
MECHANICAL
STOP POSITION
INDICATOR
STROKE
POSITION
INDICATOR
