Dukane P220 - Operating Safety Switch Detail; E-Stop Switch Detail

SECTION 5 | CONTROLS AND INDICATORS
35
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Operang Safety Switch Detail
E-Stop Switch Detail
Figure 5-8
Figure 5-7
ACTIVATION/
FAULT LED
POWER LED
ACTIVATION AREA
PUSH TO
ACTIVATE
TWIST CLOCKWISE TO RELEASE
