SECTION 5 | CONTROLS AND INDICATORS
31
403-624-00 P220 Pneumatic Ultrasonic Press System USER MANUAL
Figure 5-3
Pneumac Controls, Gauge, and Ultrasound Indicator


speed.






PRESSURE REGULATOR 2
SELECTOR BUTTON
PRESSURE GAUGE
DOWN SPEED
FLOW CONTROL
PRESSURE REGULATOR 1,
WELD PHASE
PRESSURE REGULATOR 2,
HOLD PHASE
ULTRASOUND ACTIVE
INDICATOR
