D. PROGRAMMING THE CONTROL
D-1.0 Entering Program Mode
TherearetwolevelsofcontrolProgramming.
Level1:Reciperelatedprogramming.
Level2:Broilerfunctionalityprogramming.
PressandholdtheENTERbuttonfor5seconds.
ThecontrolwillthendisplayCodE.Enterapassword
thatisspecictothelevelofprogramming.
D-2.0 Navigating the Programming Screens
TheENTERkeyisusedtomoveforwardthoughthe
listofparameters.TherstpressoftheENTERkey
bringsuptheparameternameandthenextpressbring
uptheeditableparametersetting.
The and keyswillmovebackwardthroughthe
parameters.
The and  keys will scroll through parameter
settingsandalsofunctionasnumbers0and9.
Productkeys1-8alsofunctionasnumberkeys1-8.
D-3.0 Level 1 Programming
Enterthepassword1-8-2-7andpresstheENTERkey.
Atthispointthe control will display  PRODandall
ProductLED’swillturngreen.
Select a product key for a product that you wish to
change.TheLEDnexttotheselectedproductwillturn
green.AllotherproductLEDwillbeblank.
D-3.1 Product Identier AbCd
Thisparameterallowstheusertodeneafourdigit
alphanumeric product name to associate with each
product button.
The and  keys are used to move through the
characterset.
The and keysareusedtomovetothenext
orpreviouscharacter.Thecharacterthatisactive
willash.
Hitting afterthelastcharacterwilltakeyoutothe
next parameter.
D-3.2 Cooking Temperature Cooking Prole ti1 ,
SEt1 , PL 1 , bH1 , ti2 , SEt2 , PL 2 , bH2 …
Denesthecyclingparametersfortheupperinfrared
elements,dischargeheatingelementandtheoverall
cook time.
Theseparameterscanhaveupto6segments.Each
segmentconsistsof(1)timercycle,(1)temperature
setting and (1) power level setting, and (1) bottom
heatsetting.
The bottom heat setting bH1-6 controls the lower
discharge heating elements. Changing this setting
to off turns the lower discharge element off for this
segmentofthecook
Thetimercyclesettingwillcomerst.
