Installation and Operation of Flexible Batch Broiler – Electric
8
D. ADJUSTMENTS AT INSTALLATION
Eachbroilersectionandallitscomponentpartshave
beentestedthoroughlyandinspectedbeforeyourbroiler
wasshippedfromthefactory.However,itissometimes
necessarytofurthertestoradjustthebroileronceithas
beeninstalled.Suchadjustmentsaretheresponsibility
oftheDealerorInstaller.Thesetypesofadjustments
arenotconsidereddefects,ratheranormalandroutine
partoftheproperinstallationoftheequipment.
Theseadjustmentsincludebutarenotlimitedto:
•Broilerheightadjustment(ifrequired)
Noinstallationshouldbeconsideredcompletewithout
properinspectionand,ifnecessary,anyadjustments
byqualiedserviceorinstallationpersonnel.
It is also important not to obstruct the natural ow
ofventilationairifthebroiler is to operate properly.
Thisbroilershouldnotbeinstalledonacurbbaseor
sealedtothewall.Eitherconditioncanpreventproper
ventilation of the unit.
Beforemakinganyconnectionstothebroiler,checkthe
ratingsplatetobesurethebroilerspecicationsconcur
withthevoltagetobesuppliedtothebroiler.
Theratingplateislocatedonthebackofthelowercontrol
compartment cover panel on the right end of the unit.
Theplatebearingthebroiler’smodelnumberandserial
numberisattachedtothebacksideoftheunit.
Raise or Lower Broiler
Thebroilerheightcanbeadjustedviatwoscrewson
each leg.
Caution: The Broiler is very heavy! Use adequate
help for lifting.
1. Liftoneendofthebroilerontoawide,sturdystand
(notsupplied).
2. Remove (2) screws per leg and raise/lower to
threadedholes.Reinstallscrews.
3. Removestandandsafelyraise/lowerbroiler.
4. Placeplasticholeplugs(suppliedattachtostand)
inanyunusedholes.
Support
broiler here
Screw
Slide Leg.
Reinstall screws.
Plastic Hole Plug
