60
Is harness plugged into Supply
Water Sensor?
Is harness plugged into Control
Module J5?
_ P _ _ _
Blocking Error E 5 1
Supply Sens Open
Insert Harness
Replace Supply
Water Sensor
Disconnect J5 from Control
Module. Using digital meter
measure check continuity of
brown wires between Control
and Sensor. Continuity?
Using digital meter measure
resistance between Supply
Water Sensor terminals J5-11
and J5-3. Measure resistance
of Sensor with digital meter.
Estimate Sensor temperature.
Does it fall in the range of the
Resistance Chart?
Replace Wires
50 to 9010 to 32 9K to 24K ohms
150 to 200
90 to 130
°F°C Resistance
130 to 150
2K to 1K ohms
2K to 3K ohms
3K to 9K ohms
54 to 66
32 to 54
66 to 94
Supply Water Sensor
Resistance Chart
Disconnect field wiring. Is
continuity between field wiring
neutral and ground less than
10 ohms?
Is field grounding conductor
connected to High Voltage
Terminal Strip 120 VAC (G)?
NOYES
_ P _ _ _
Blocking Error E 4 6
Faulty ground
Connect ground
conductor
YES NO
Correct faulty ground
conductor
Replace Control
Module
NOYES
YES NO
YES NO
Replace Control
Module
13 - TROUBLE SHOOTING
To Next Page
