Duplo DBM-120 - Stapler Folder; Table of Contents

11C-M12M0-0004-0
TABLE OF CONTENTS
CHAPTER 1 MECHANISM
1. Outline of Each Mechanism and
Adjustments ....................................................1-2
2. Maintenance ...................................................1-11
CHAPTER 2 ELECTRICAL
COMPONENTS
1. Block Diagram of Structure and Outline of
Each Block ......................................................2-2
2. Errors and Causes ..........................................2-10
3. Maintenance Mode .........................................2-17
4. Precautions on Replacing the MC Unit ...........2-19
5. Precautions on Replacing Fuses ....................2-20
6. LCD Map .........................................................2-21
7. Overall Schematic Diagram ............................2-27
8. Wiring Diagram ...............................................2-28
