2-16
11C-M12M0-0004-0
Display Description
Top Cover Open
Trimmer Error
Staple ∗ Nearly Empty
∗: L, R, (Blank)
The contact of the cover switch is open.
<Other causes>
The door is not closed completely.
Malfunction of the switch
Faulty connection between the switch and MC unit
Malfunction of the MC unit
An error signal was received from the trimmer.
<Other causes>
Jam occurred at the trimmer.
The top cover of the trimmer is open.
An error other than jamming occurred at the trimmer.
Faulty connection between the trimmer and MC unit
Malfunction of the MC unit
Malfunction of the trimmer
The staples in the stapler ∗ are running out.
<Other causes>
Faulty connection between the stapler ∗ and MC unit
Malfunction of the stapler ∗
Malfunction of the MC unit
-------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------
2-3. Other Condition Messages
The control panel also displays messages of other conditions of the machine such as when a door is opened, etc. The
causes of such messages are shown below. In some cases, if the message and actual condition differ such as when
“Top Cover Open” is displayed despite the door being closed, an error may be suspected. Details are provided below.
Condition display
