76
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Take out a new master roll from the bag.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Set the master roll in the direction as shown in
the illustration at right.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Pull out the master , and insert the master
aligned with the loading line under the guide
panel until it contacts the roller.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Close the master cover.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Push the master set lever.
The master is pulled in.
IMPORTANT
• If the master is not pulled in open the master
cover, and gently press in as far as possible
to set again.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Replacing the Master Roll
Master cover
Master
set lever
To Next Page
