6
Display Screen:
NOTE:
The “
C:
” size may very from cutter to cutter.
C: Current cut position.
The backgauges current position.
PROG: Program number.
There are 9 programs from 1 - 9. The
PROG: 0
is for parameter
setting, any changes on the parameter should be made in the
configuration mode.
1: 2: 3: 4: 5: 6: 7: 8: Cut position.
It allows for 9 programs with 8 cuts each. Two or more programs can
be combined. A total of 72 cuts can be stored.
C: 26”125 PROG: 1 AUTO
1: 17”000 2: 11”000
