STEP 4: Install the electric auxiliary heating assembly and note that the support
assembly must lock into the support holes in the back of the cabinet.
STEP 5: Tighten the mounting screws.
STEP 6: Connect the wiring according to the wiring diagram on page 32. Attach the
wiring diagram sticker provided to the inside of the front cover for future reference.
STEP 3: Remove the terminal block and power wires, loosen the screws, and
remove the electric auxiliary heating cover.
Screws
Screws
Supports
Top View
To Next Page
