POWER SPECIFICATIONS
Indoor Units Without Electric Heat
Model Number MCA (A) MOCP (A) Volts-Phase Motor HP FLA (A)
DRAM30S1A 4.5 15 208/230-1 1/2 3.5
DRAM36S1A 5.0 15 208/230-1 1/2 4.0
DRAM48S1A 7.5 15 208/230-1 3/4 6.0
DRAM60S1A 9.0 15 208/230-1 3/4 7.0
Model Number MCA (A) MOCP (A)
Voltage
Range (V)
Cooling
Current (A)
Cooling Input
Power (W)
Heating
Current (A)
Heating Input
Power (W)
DRA1U30S1A 20 35 187-253 13.20 2835 12.40 2795
DRA1U36S1A 24 40 187-253 15.82 3560 15.80 3110
DRA1U48S1A 34 50 187-253 23.20 5320 22.50 5117
DRA1U60S1A 34 60 187-253 29.00 6475 20.90 5085
Outdoor Units
WARNING
While connecting the wires, strictly follow the wiring diagram, and refer to the
nameplate for electrical information. Wire according to NEC and local codes.
