1. Diagrams and pictures
1.1 Actuator plate
LED display on the actuator plate
Orange Emergency power mode, limited functionality
Flashing blue Settings are controlled via remote control
Minimum or maximum range has been reached (flashes
3times in succession)
Odour extraction Short flush
Long flush
LED
LED
