Caution! Danger of injury!
Turn off main switch!
The shuttle bobbin must not be changed unless the
machine is switched off.
–
Change the bobbin.
A new seam can now be sewn.
IMPORTANT !
The bobbin must be put in place with the groove 2 facing
downwards.
The area of the spool housing and the light barrier must be
kept free of dust.
If the empty bobbin is not replaced by a full one, the acoustic
signal sounds again when the next seam is sewn.
Depending on the s etting:
- Either the signal sounds continuously all the time the seam is being sewn until
the thread is cut
- or it sounds for 2 seconds the next time the thread is cut.
–
Winding on spool thread.
The procedure is described in this operating manual.
IMPORTANT !
The groove 2 must face upwards for winding on.
Wind the thread round the spool manually only in the area
of the supply groove 4.
33
GB
2
3
4
