10.4 Upper and lower conveyor rollers SP 470
The removal of the material by the upper and lower conveyor rollers after s ewing
ensures a smooth and uniform product.
The speed with which the material is removed can be exactly matched to the stitch
length. The pressure can be set at a level appropriate to the material.
–
Lever 1
Matches the speed of the upper and lower conveyor rollers to the stitch length set.
–
Screw 2
Adjusts the upper conveyor-roller pressure to the material being processed.
–
Lever 3
Lowers the upper conveyor roller.
37
GB
1
2
3
