6.9 Raising the sewing feet
The
class 768
pillar sewing machine is fitted with the electro-pneumatic sewing-foot lift
(FLP) as standard. This enables the sewing feet to be raised during sewing.
–
Push pedal half-way back.
–
The sewing machine halts in the 1st position (needles down).
Raising the sewing feet.
–
Release pedal.
–
Push pedal forwards.
The sewing machine begins sewing at the rate set by the pedal.
6.10 Locking the sewing feet in the up position
The electro-pneumatically raised sewing feet are locked in the up position with the
lever 1 (e.g. to spool the looper thread or change the sewing feet).
The lever 1 is located at the rear of the sewing-machine arm.
–
With the machine at a halt push the pedal half-way back.
Raising the sewing feet.
–
Swivel lever 1 down.
The sewing feet are locked in the up position.
–
Swivel lever 1 up.
The sewing feet are no longer locked.
1
GB
15
