Page #27 background imageLoading...
Page #27 background image
10.2 Lubrication
Caution - danger of injury!
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
CAUTION!
The handling and disposal of mineral oils is subject to legal
regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only
ESSO SP-NK 10
lubricating oil
or an equivalent oil of the following specification:
viscosity at 40° C : 10 mm2/s
flashpoint: 150 °C
ESSO SP-NK 10
is available from
DÜRKOPP-ADLER AG
retail outlets under the
following part numbers:
2-litre container: 9047 000013
5-litre container: 9047 000014
maintenance work explanation operating
to be carried out hours
- Lubricating the sewing
head and the lower part of
the sewing machine.
Remove stopper 1.
- Top up with oil.
- Check the oil level at the sight glass 3.
The oil level must always be above
the red
"full"
line.
- Replace stopper 1.
- Remove any oil spillage from the oil
collector.
8
- Lubricating the shuttle. - Use the oil can (in the accessory pack)
to drip a few drops of oil into hole 4 in
the shuttle-plunger ring 5
(there is no recirculation lubrication)
3
- Inspecting the oil supply
to the sewing head.
- Inspect the oil supply
during operation
at the viewing
window 2.
- if no oil flow is visible at the viewing
window, inform the service technician.
8
GB
29
