SDI-01
Feb ‘15
- 16
Compressor Pump – DEV-30-1
No. Part Number: Qty: Description:
1
PB-21175002 2 Air Filter Assembly
PB-21177012 2 Air Filter Element
2 VRK-40 2 Valve Repair Kit
3 PB-21166003 1 Crankcase Breather
4 PB-21164004 1 Oil Sight Glass
5 PB-21177001 1 Fan Assembly
6 PB-21177025 1 Shroud Assembly
GK-40 1 Gasket Kit
Note: 1. The ‘VRK-40’ Valve Repair Kit includes the Valve
Plates and the Gaskets necessary to install them.
2. The previous ‘DEV-30’ Pump did not have the Fan
Assembly and Shroud Assembly. All other
components remain the same.
Maintenance Kits:
The appropriate Maintenance Kit for the ‘DEV-30’ Pump is the part number ‘MK-40’ and includes the following:
(3) PB-21177012 Filter Elements
(1) PR-31-4 30 Weight Mineral Oil – 4 litre jug
