SDI-01
Feb ‘15
- 17
Compressor Pump – DEV-40
No. Part Number: Qty: Description: No. Part Number: Qty: Description:
1
PB-21175002 3 Air Filter Assembly 6 PB-21166001 1 Crankcase Breather
PB-21177012 3 Air Filter Element 7 PB-21164004 1 Oil Sight Glass
2 VRK-40 3 Valve Repair Kit 8 PB-21177001 1 Fan Assembly
3 PB-21167002 1 Oil Fill Plug 9 PB-21177020 1 Shroud Assembly
4 PB-21161004 1 Oil Seal GK-40 1 Gasket Kit
5 PB-21212003 1 Flywheel OK-40 1 Overhaul Kit
Note: 1. The ‘VRK-40’ Valve Repair Kit includes the Valve Plates and the Gaskets necessary to install
them.
2. The previous ‘DEV-40’ Pump did not have the Fan Assembly and Shroud Assembly. All other
components remain the same.
3. ‘OK-40’ Overhaul Kit includes (1) Gasket Kit, (1) Ring Kit, (3) Valve Repair Kits, and (1) Oil Seal.
Maintenance Kits:
The appropriate Maintenance Kit for the ‘DEV-40’ Pump is the part number ‘MK-40’ and includes the following:
(3) PB-21177012 Filter Elements
(1) PR-31-4 30 Weight Mineral Oil – 4 litre jug
