Formats
For DVI output, the Sync type is always separate Hsync and
Vsync, and the colorspace is always RGB. For analog output, the
factory default format is 480p as shown in the table. Once you
override the sync and colorspace selection, future format selec-
tions will not affect the sync type and colorspace. The predefined
formats 720p, 1080i and 1080p are compliant with the CEA-861B
specification for DVI output. Each format has two timing modes,
one for 50Hz inputs and the other for 60Hz inputs.
Input Select Control
The Input Select control enables you to select one of the nine
(9) inputs of the iScan HD
+. When this button is first pressed,
the front panel display (FPD) shows the current selected input.
When this button is pressed again, it selects the next input on
the list. When you’ve reached the last input, pressing the button
again selects the first input on the list and the process repeats.
You can also cycle through the inputs by pushing this button
once and then pressing the
▼ or ▲ arrow buttons.
The table below shows the list of inputs in the order that they
are cycled through using the
Input Select button. The location
of the connectors is shown on page 4.
The Input Select indicator (LED), the front panel display (FPD)
and the on-screen display (OSD) will turn on when the button
is pressed. The indicator will turn green if the selected input is
active and red if it is not active. The Input Select LED, FPD and
OSD will turn off automatically after 30 seconds. If the input is
not active, the LED will remain red.
9
Input
Select
Control
Displays and Controls (continued)
Horizontal
Resolution
Vertical
Resolution
Scan
Type*
FPD
shows
Sync
Signal
Line(s)
Sync
Signal
Type
Color-
space
720 480 P 480P Y Bi-level YPbPr
1920 540 P 540P Y Tri-level YPbPr
720 576 P 576P Y Bi-level YPbPr
1280 720 P 72P5 Y Tri-level YPbPr
1280 720 P 72P6 Y Tri-level YPbPr
1920 1080 I 18I5 Y Tri-level YPbPr
1920 1080 I 18I6 Y Tri-level YPbPr
1920 1080 P 18P5 Y Tri-level YPbPr
1920 1080 P 18P6 Y Tri-level YPbPr
640 480 P VGA H-V- - RGB
800 600 P SVGA H+V+ - RGB
1024 768 P XGA H-V- - RGB
1280 1024 P SXGA H-V- - RGB
852 480 P PLA1 H-V- - RGB
852 576 P PLA2 H-V- - RGB
1366 768 P PLA3 H-V- - RGB
1280 768 P PLA4 H-V- - RGB
1024 1024 P PLA5 H-V- - RGB
1024 852 P PLA6 H-V- - RGB
1024 576 P DLP1 H-V- - RGB
848 600 P DLP2 H-V- - RGB
1365 1024 P DIL1 H-V- - RGB
1400 1050 P DIL2 H-V- - RGB
1400 788 P DIL3 H-V- - RGB
960 540 P LCD1 H-V- - RGB
1280 960 P QUA1 H-V- - RGB
1440 960 P QUA2 H-V- - RGB
1440 1152 P QUA3 H-V- - RGB
* P = progressive; I = interlace
Preset Formats and Characteristics for Analog Video Output
Input FPD shows Description
Video 1 VID1 Composite Video 1
Video 2 VID2 Composite Video 2
S-Video 1 SVD1 S-Video 1
S-Video 2 SVD2 S-Video 2
Component 1 /
RGBS 1
COM1 Component Video 1 - This input accepts either a YPbPr or RGBS signal. The input is configured for YPbPr by default,
and switches to RGB when a connector is plugged into the Sync 1 input. This input will accept 480i, 480p, 576i and
576p formats. All other formats will be passed through to the analog output unprocessed.
Component 2 /
RGBS 2
COM2 Component Video 2 - This input accepts either a YPbPr or RGBS signal. The input is configured for YPbPr by default,
and switches to RGB when a connector is plugged into the Sync 2 input. This input will accept 480i, 480p, 576i and
576p formats. All other formats will be passed through to the analog output unprocessed.
Analog Passthru PASS Analog Passthru is selected. This signal is passed through to the Analog Output unprocessed.
DVI DVI DVI Input - The DVI input accepts 480p, 576p, 720p and 1080i formats. If the content is copy-protected by HDCP,
the iScan HD+ will output the processed signal on the DVI output with HDCP or if the analog output is selected, the
iScan HD+ will output blue screen. Non HDCP signals will be output on either the DVI output or analog output.
Other input formats are passed through to the DVI output unprocessed.
SDI* SDI SDI Input. – This input accepts either a 480i or 576i signal from an SDI source.*
*SDI Video Input Module required.
Automatic
Input Selection
AUTO Automatic active input selection - Automatically selects an input from among all currently active inputs based on an
internal priority list. The factory default list is shown below from highest to lowest priority. You can assign different
priorities to the iScan HD+’s video inputs using the Configuration control then selecting AutoSource (IPSL).
Note: The DVI input and Analog
Passthru functionality is depen-
dent on which output is selected.
1- Component / RGBS 1
2- Component / RGBS 2
3- S-Video 1
4- S-Video 2
5- Video 1
6- Video 2
7- DVI
8- SDI*
9- Analog Passthru
