DVDO iScan HD+ - Technical Specifications; Inputs; Outputs; Controls

Inputs
䊳
Nine video inputs
㛮
Two Composite inputs accept standard NTSC, PAL, and
SECAM signals
㛮
Two S-Video inputs accept standard NTSC, PAL,
and SECAM signals
㛮
Two Component Video inputs (YPbPr or RGBS) process
480i, 480p, 576i, 576p signals; pass-through 720p and
1080i High Definition signals
㛮
One VGA Analog Passthru input – VGA HD15 connector
㛮
One DVI input – DVI-I connector processes 480p, 576p,
720p, 1080i signals; HDCP compliant
㛮
One SDI input – (requires DVDO SDI Video Input Module)
䊳
Four digital audio inputs - can be assigned
individually to any of the video inputs:
㛮
Two Digital Optical inputs
㛮
Two Digital Coaxial inputs
䊳
Accepts S/PDIF Dolby Digital, DTS, LPCM @ 44Ksps
to 96 Ksps, 16 bits to 24 bits
Outputs
䊳
One Digital Video Output – DVI-I connector HDCP compliant
䊳
One Analog Video Output – VGA HD15 connector
㛮
RGB or YPbPr colorspace
㛮
Separate H+V sync, composite sync,
or sync-on-video (bi-level or tri-level sync)
䊳
Two digital audio outputs
㛮
One Digital Optical output
㛮
One Digital Coaxial output
Controls
䊳
Infrared remote control with direct access codes
or manual controls on front panel
䊳
Functions accessible via either On Screen Display (OSD)
or front-panel LED display
䊳
Fully programmable controls for each separate video
input with non-volatile memories:
- Automatic input source detection and input priority
selection
- Input aspect ratio select: 4:3 fullframe, 4:3 letterbox,
16:9 fullframe or custom input aspect ratio*
- Output aspect ratio select: 4:3, 5:4, 16:9 or custom
output aspect ratio*
- Flexible horizontal and vertical Zooming and
Panning controls
- Picture controls with memory for each input: Brightness,
Contrast, Saturation, Hue, Y/C Delay, Sharpness
䊳
Output Controls: Analog/Digital, Format/Resolution,
Aspect Ratio, Sync Type, Colorspace (RGB or YPbPr),
Frame Lock, Display Profile*
䊳
RS-232 automation/control interface with upgradeable
software
䊳
Built-in test patterns for ease of set up
䊳
Power
㛮
Universal AC mains input:
100 - 240 VAC @ 50 - 60 Hz
㛮
Consumption < 30W
㛮
Sleep mode - automatic 30 second timeout
indicated by power indicator color change
䊳
Physical
㛮
Dimensions 10.4" x 17"x 2.2" (26.3cm x 43.3cm
x 5.5cm) with desktop feet
㛮
Standard 19" 1U 1.75" rackmount option
䊳
Weight
㛮
Shipping – 10.5 lb (4.8 kg)
㛮
Unit (without power supply) – 6.4 lb (2.9 kg)
䊳
Optional rackmount brackets,
order part number: 99-1211-02
* feature available with future firmware upgrades
