4 SPECIFICATION
4.1 SPECIFICATION
TECHNICAL DESCRIPTION
The mower is a self-propelled machine with four-wheel drive, controlled by the transmitter (remote radio
controller) signal. Its unique wheel-steering technology ensures a high manoeuvrability both on level ground and
on slopes.
The basic part of the machine is formed by a square solid frame, which is connected with a sliding frame. The
middle part of the sliding frame carries all transmission parts such as the engine, the hydraulic pump, the oil
cooler and the control unit. A cutter blade is attached to the bottom part of the frame. An electromagnetic clutch
is placed between the blade carrier and the engine.
Transmission is by chains and gears on all four wheels. The wheels are driven centrally by the hydraulic drive
through V-belts. The wheels are steered by an electric motor.
The control unit is situated in a box above the cover of the gel battery. The mower is controlled by a multi-
channel transmitter.
60 - 110 (2,36 – 4,33); 30 - 80 (1,18 - 3,14)
continuous regulation
0 – 3, 0 – 7 (0-2, 0-4,5)
Single-balde with a fixed balde attached by the
flange int the middle
Electromagnetic with a friction brake
16x6,5 - 8 with and arrow (V) tread pattern
Air-cooled four-stroke two cylinder
Kawasaki FH500V FH531V Kohler CV18S
Frequency range of the
Remote controller NBB for
EU and USA
4.2 NOISE EMISSIONS
The mower emits the following noise: Sound pressure level L
WA
= 98,9 dB
Guaranteed Sound pressure level L
WA
= 100 dB
The measuring was carried out in conformity with EN ISO 3744
Noise at the operator’s station (ear): L = 85 dB (A) Leq – Measured in the distance of 1m from the machine
according to EN 11201
