Operation manual - Spider ILD01
25 / 52 rev. 10-01-05-2011
9. PREPARING THE MACHINE
9.1 MACHINE DELIVERY TO A DEALER
OR RETAILER
From the manufacturer the machine is
delivered filled with engine oil and
hydraulic oil but without gasoline in the tank.
The training of the operator should take place during
the installation of the product.
The mower may be delivered on a wooden pallet or in
a crate.
To take the mower off the pallet
• Place the palette with the mower on a level
surface
• Carefully remove the upper boards of the
crate and take out all accessories & the
remote control Disassemble the side boards
of the crate
• Release the attachment fastening the
mower to the pallet, remove transportation
wrapping. Recycle these wraps.
• Thoroughly examine the mower for possible
damage and missing parts from the
delivery. If necessary, contact the
transporting company with your claim.
• Before driving down from the pallet raise the
mowing mechanism to the upper position
(this can be done without starting the
engine)
• Place boards in front of the wheels in the
direction, in which you expect to drive the
mower from the pallet to the ground. Put at
least 5 litres of fuel to the tank and attach
cables onto the battery. While starting,
follow instructions in chapter 5.
• The aerial must be attached to the mower
• After starting the engine set the speed
controller on the transmitter to the (L)
symbol – lower driving speed
• Slowly move the forward/reverse joystick to
correspond with the direction you want to
move the mower. The arrow on the wheel
legs indicates forward.
• Slowly drive down to the ground and stop
the engine
• While unpacking, assembling and preparing
the mower, do not engage the mower blade.
Součásti dodávky:
• SPIDER mower
• Mower ignition key (X2)
• Gel battery (12v starting)
• Remote control including 2 batteries
• Remote control battery charger (12v – 12v)
• Operation manual
• Radio controller key (X2)
• Engine user’s and maintenance manual
• RC instruction manual
• Copy of the EC declaration of conformity
• Copy of the EC declaration of konformity for
Remote controller NBB
If you have a lifting device with a
sufficient lifting capacity
available, place the lifting
hooks/eyes on spots marked with the symbols
of chain, lift the load by about 0,15 m (6inch),
move the pallet away from the mower and
lower the machine to the ground.
There may not be enough fuel in
the fuel system when starting for
the first time and you may need
to repeat the starting several times. Starting
period must not exceed 3 seconds. There
must be a pause of at lest 20 seconds
between all attempts to start the engine.
