ASSEMBLY INSTRUCTIONS
10. Slide the 6 cooking grates (E) onto the top
cooking grate supports (F) inside the smoker
body (G).
11. Place the charcoal chamber (N) directly onto
the charcoal grate (M) and slide the grate onto
the support brackets located on the inside of the
smoker body - right (J). Slide the ash tray (L)
under the support brackets.
12. Slide the grease cup (I) to the grease cup support
of the smoker body-left (G) bottom.
I
G
12
E
G
F
