Dyna-Glo DGP321SNN - Page 9

9
ASSEMBLY INSTRUCTIONS
5. Attach the upper front door brace (V) to the cart
left side panel assembly (L) and the cart right
side panel assembly (G) with four M6x35
bolts (EE).
6. Attach the door magnet (X) to the cart left side
assembly (L) with four M3x10 bolts (FF).
Hardware Used
EE
M6x35 Bolt
x 4
V
EE
G
L
5
G
EE
V
L
Hardware Used
FF
M3x10 Bolt
x 4
X
FF
G
L
6
L
G
FF
X
