5
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Hood Handle 1
B Temp Gauge 1
C Grill Body Assembly 1
D Side Shelf Bracket A 2
E Right Side Shelf Assembly 1
F Side Shelf Bracket B 2
G Cart Right Side Panel Assembly 1
H Locking Swivel Caster 2
I Non-Locking Swivel Caster 2
J Cart Bottom Panel Shelf 1
K Bottom Panel Skirt Assembly 1
L Cart Left Side Panel Assembly 1
M Door Assembly 1
PART DESCRIPTION QUANTITY
N Door Handle 1
O Left Side Shelf Assembly 1
P Heat Tent 3
Q Cooking Grate 2
R Warming Rack 1
S Control Knob 3
T Grease Pan 1
U Grease Cup 1
V Upper Front Door Brace 1
W Cart Rear Panel 1
X Door Magnet 2
Y Natural Gas Hose Holder 2
Z Quick Disconnect Coupling 1
B
C
D
A
E
G
I
F
H
Z
N
O
M
P
R
Q
T
S
V
U
W
X
Y
L
K
J
