5
D
A
B
C
E
F
G
H
I
N
O
P
Q
R
M
K
J
L
T
S
U
V
W
X
PACKAGE CONTENTS
B
C
D
A
G
E
IJL
N
O
M
P
R
V
T
S
U
W
X
Q
F
H
K
PART DESCRIPTION QUANTITY
A Hood Handle 1
B Temp Gauge 1
C Grill Body Assembly 1
D Side Shelf Bracket A 2
E Right Side Shelf Assembly 1
F Side Shelf Bracket B 2
G Cart Right Side Panel Assembly 1
H Locking Swivel Caster 2
I Non-Locking Swivel Caster 2
J Cart Bottom Panel Shelf 1
K Bottom Panel Skirt Assembly 1
L Cart Left Side Panel Assembly 1
PART DESCRIPTION QUANTITY
M Door Assembly 1
N Door Handle 1
O Left Side Shelf Assembly 1
P Heat Tent 3
Q Cooking Grate 2
R Warming Rack 1
S Control Knob 3
T Grease Pan 1
U Grease Cup 1
V Upper Front Door Brace 1
W Cart Rear Panel 1
X Door Magnet 2
