PACKAGE CONTENTS
D
A
B
C
E
F
G
H
I
J
X
Y
L
V
W
S
T
U
R
Q
K
O
A1
Z
P
M
N
A2
A
B
C
D
E
F
G
H
I
J
L
X
W
V
Y
K
M
N
A1 A2OZP
Q
R
S
T
U
PART DESCRIPTION QUANTITY
A Hood Handle 1
B Temp Gauge 1
C Grill Body Assembly 1
D Side Burner Rack 1
E Right Side Burner Body Assembly 1
F Side Burner 1
G Right Side Burner Control Panel 1
H Control Knob Bezel 1
I Control Knob 6
J Door Handle 2
K Right Door Assembly 1
L Cart Right Side Panel Assembly 1
M Locking Swivel Caster 2
N Non-Locking Swivel Caster 2
PART DESCRIPTION QUANTITY
O Bottom Panel Skirt Assembly 1
P Cart Left Side Panel Assembly 1
Q Left Door Assembly 1
R Quick Disconnect Coupling 1
S Heat Tent 5
T Cooking Grate 3
U Warming Rack 1
V Left Side Table Assembly 1
W Grease Pan 1
X Grease Cup 1
Y Upper Front Door Brace 1
Z Cart Rear Panel 1
A1 Cart Bottom Panel Shelf 1
A2 Natural Gas Hose Holder 2
