Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product. Please read and understand this entire manual before at-
tempting to assemble, operate or install the product. If you have any questions regarding the
product, call our customer service department at 1-877-447-4768, 8:00 a.m.- 4:30 p.m. CST,
Monday - Friday.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly (not included): Phillips Screwdriver
PREPARATION BEFORE ASSEMBLY
HARDWARE CONTENTS (PRE-ASSEMBLED)
M4 x 35 mm
Screw
Qty. 8
8 M4 x 35 mm screws
(AA) are pre-assem-
bled in each of the 2
door handles (upper
door/lower door) (E).
M6 x 12 mm
Screw
Qty. 6
6 M6 x 12 mm screws
(BB) are pre-assem-
bled in the smoker
cabinet assembly (A).
M5 x 12 mm
Screw
Qty. 12
12 M5 x 12 mm
screws (CC) are
pre-assembled in the
smoker cabinet as-
sembly (A).
CCBB
AA
