Amplifier model L1300FD/C1300FDi
Color Black
Dimensions (W x H x D), mm 483 x 88 x 462.4
Weight 12.9 kg (28.4 lb)
Remote Power ON /GPIO
(C Series only)
Power remote via switch, delay time selectable
Floating relay contacts (show protect mode)
Inputs for preset selection
Signal Processing FIR Filters, Audio Limiters
Output delay per channel,
31 band GEQ per channel,
PEQ per channel,
Load impedance
Accessories RMK15 (rear rack mount kit), Multi Amplifier Remote Control
(MARC) software
Test signal for max. output power according IHF-A-202 (Dynamic-Headroom, burst 1 kHz/20
ms on/480 ms off/low level -20 dBu).
Amplifier model L1800FD/C1800FDi
Load Impedance 2 Ω 2.6 Ω 4 Ω 8 Ω
Maximum Output Power, Single Channel 1600 W 1300 W 950 W 480 W
Maximum Output Power, Dual Channel 1400 W 1200 W 850 W 450 W
Maximum Output Power, Bridged - - 2800 W 1700 W
Maximum RMS Voltage Swing
THD = 1%, 1 kHz
65.1 V
Voltage Gain
Ref.1 kHz
32.0 dB
THD at 600 W/4
Ω
MBW = 80 kHz, 1 kHz
< 0.05%
IMD-SMPTE,
60 Hz, 7 kHz
< 0.1%
DIM30
,
3.15 kHz, 15 kHz
< 0.05%
Maximum Input Level +21 dBu
Crosstalk
ref. 1 kHz, at 100 W/4
Ω
< -80 dB
Frequency Response
,
ref. 1 kHz
10 Hz to 21 kHz (±1 dB)
Input Impedance,
Active Balanced
20 k Ω
30 en | Technical data
L Series and C Series FIR-Drive Power
Amplifiers
2017.10 | 02 | F.01U.327.801 Installation manual Bosch Sicherheitssysteme GmbH
