Model Load Capability Dual Channel Load Capability Bridge Mode
C1800FDi 2 x 1250 W
(-1.5 dB)
Not available
2
Not
recommended
1
1 x 1250 W
(-1.5 dB)
C1300FDi Not available
2
1 x 625 W
(0.0 dB)
Not available
2
Table 8.1: C Series direct drive load capability
1
This operation mode is not recommended due to the efficiency reasons. Please use the next
smaller amplifier for this mode.
2
Direct drive mode not available for this configuration.
Notice!
100 V: 2 x 2500 W means each channel of the amplifier may be loaded with a maximum 2500
W loudspeaker loads.
For example, 50x loudspeakers per channel, each loudspeaker with a power rating of 50
W/100 W.
Mains operation & resulting temperature
The power drawn from the mains network is converted into output power to feed the
connected loudspeaker systems and into heat. The difference between power consumption
and dispensed power is called power dissipation (Pd). The amount of heat resulting from
power dissipation might remain inside of a rack-shelf and needs to be diverted using
appropriate measures.
Mains operation & resulting temperature tables allow the determination of power supply and
cabling requirements. The tables are meant as auxiliary means for calculating temperatures
inside of a rack-shelf system/cabinet and the ventilation efforts necessary.
The column Pd lists the leakage power in relation to different operational states. The column
BTU/hr lists the dispensed heat amount per hour. Power consumption is direct proportional
for other mains voltages. The following conversion factors are meant for easy conversion: 100
V = 2.3; 120 V = 1.9; 240 V = 0.96.
Power consumption
C1300FDi
Output Power
U
mains
[V]
I
mains
(5)
[A]
P
mains
[W]
P
out
[W]
Pd
(4)
[W]
BTU/hr
(3)
Idle 230 0.5 43 - 43 146
1/8 Max. Output Power @ 8Ω
(2)
230 2.1 330 2 x 40 250 853
1/8 Max. Output Power @ 4Ω
(2)
230 3.5 572 2 x 75 420 1435
1/8 Max. Output Power @
2,66Ω
(2)
230 4.7 808 2 x 106 596 2036
1/8 Max. Output Power @ 2Ω
(2)
230 5.4 980 2 x 125 730 2490
1/8 Max. Output Power @ 4Ω
(1)
230 3.9 630 2 x 75 480 1638
Rated Output Power @ 8Ω
(1)
230 4.4 730 2 x 200 330 1126
8.2
L Series and C Series FIR-Drive Power
Amplifiers
Technical data | en 35
Bosch Sicherheitssysteme GmbH Installation manual 2017.10 | 02 | F.01U.327.801
