Amplifier model L3600FD/C3600FDi
Power Consumption
1/8 Maximum Output Power @ 4 Ω
850 W
Mains Fuse 240 V/230 V: T15AH; 120 V/100 V: T30AH
Protection Audio limiters, high temperature, DC, HF, Back-EMF, Peak current
limiters, Inrush current limiters, Turn on delay
Cooling Front-to-rear, 3-stage-fans
Ambient Temperature Limits +5°C to +40°C (40°F to +105°F)
Safety Class I
Color Black
Dimensions
(W x H x D), mm 483 x 88 x 462.4
Weight 18.2 kg (40.1 lb)
Remote Power ON/GPIO
(C Series only)
Power remote via switch, delay time selectable
Floating relay contacts (show protect mode)
Inputs for preset selection
Signal Processing FIR Filters, Audio Limiters
Output delay per channel,
31 band GEQ per channel,
PEQ per channel,
Load impedance
Accessories RMK15 (rear rack mount kit), Multi Amplifier Remote Control
(MARC) software
Test signal for max. output power according IHF-A-202 (Dynamic-Headroom, burst 1 kHz/20
ms on/480 ms off/low level -20 dBu).
C Series direct drive load capability
The direct drive load capability is a measure for the total wattage that can be driven in 70
V/100 V operation mode. A load capability value of 1250 watts means that this amplifier can
drive e.g. 50 loudspeakers at a voltage tab of 25 watts. The dB value in parentheses indicates
the delta to maximum modulation. In cases where the maximum modulation is not required
you can use the smaller amplifier model.
Model Load Capability Dual Channel Load Capability Bridge Mode
70V Operation 100V Operation 70V Operation 100V Operation
C3600FDi Not
recommended
1
2 x 2500 W
(-1.5 dB)
Not recommended
1
C2800FDi 2 x 1250 W
(0.0 dB)
2 x 2500 W
(-3.0 dB)
Not
recommended
1
1 x 1250 W
(0.0 dB)
8.1
34 en | Technical data
L Series and C Series FIR-Drive Power
Amplifiers
2017.10 | 02 | F.01U.327.801 Installation manual Bosch Sicherheitssysteme GmbH
