CMS
3
86
Device in rated condition, unity gain (MIC gain 20 dB), all faders position 0 dB, all pots in mid position, master fader +6 dB
Display 128 x 64 pixels, OLED
Digital Audio Interface
Channels 4 In / 4 Out
AD/DA Conversion 24-bit
Sampling Rate 44.1 / 48 / 88.2 / 96 kHz
PC Interface USB2.0, Female Type B
Peak Display 6 dB before Clip
MIDI Interface 5-pin DIN connector, In / Out
Protection
Mixer Outputs (Relay controlled) MON 1, MON 2, MASTER A
Switching Mode Power Supply (µC controlled) Mains Over/Undervoltage, High Temperature
Phantom Power, switchable in groups 48 V DC
Power Requirements (SMPS with auto range mains input) 100 V to 240 V AC, 50 Hz to 60 Hz
Safety Class I
Ambient Temperature Limits +5 °C to +40 °C (40 °F to 105 °F)
Dimensions (W x H x D, without lid), mm 510.5 x 155 x 498.5
Rack-mount:
483.0 x 135.0 x 443.7
663.5 x 155 x 498.5 818.5 x 155.0 x 498.5
Weight, without lid
Net Weight 9.5 kg
(10.5 kg incl. Rack Mount
Kit))
12 kg 14.5 kg
Shipping Weight 12.5 kg 15.0 kg 17.5 kg
Warranty 36 months
Optional Accessories
Lid F01U169707
(DC-LID1000)
F01U169708
(DC-LID1600)
-
Dust Cover for CMS 2200 - - F01U169467
(DC-SH2200-3)
Rack Mount Kit for CMS 1000 F01U169471
(DC-RMK1000CMS)
--
Gooseneck Lamp, 12V/5W, 12”, XLR 4 pol. F01U118983 (DC-LITLITE-4P)
FS 11 (Footswitch with LED) F01U100598 (DC-FS11)
Property CMS 1000 CMS 1600 CMS 2200
