Dynacord CMS3 - Specifications

CMS
3
73
7 Specifications
Property CMS 600-3
Order No. F01U213891
DC-CMS600-3-UNIV
Channels 4 +2 + 2
MIC/Line-Mono 4
MIC/Line-Mono / USB-Stereo (Super Channel) 2
Line L-R / CD-IN-Stereo 2
Auxiliarys (AUX, MON) Pre/Post switchable, Pre
MIC GAIN (LINE -20 dB) +10 to +60 dB
TRIM LINE/CD (Stereo) -10 to +20 dB
THD, at 1 kHz, MBW = 80 kHz
MIC input to Master A L/R outputs, +16 dBu, typical < 0.005%
Frequency Response, -3 dB, ref. 1 kHz
Any input to any Mixer output 15 Hz to 70 kHz
Crosstalk, 1 kHz
Channel to Channel < -80 dB
Mute and Standby switch attenuation > 100 dB
Fader and FX/AUX/MON-Send attenuation > 85 dB
CMRR, MIC input, 1 kHz > 80 dB
Input Sensitivity, all level controls in max. position
MIC -74 dBu (155 µV)
LINE (Mono) -54 dBu (1.55 mV)
LINE (Stereo) -34 dBu (15.5 mV)
CD (Stereo) -34 dBu (15.5 mV)
Maximum Level, mixing desk
MIC inputs +12 dBu
Mono Line inputs +31 dBu
Stereo Line inputs +30 dBu
All other inputs +22 dBu
All other outputs +22 dBu
Input Impedances
MIC 2 kOhms
CD In 10 kOhms
All other inputs > 15 kOhms
Output Impedances
Phones 47 Ohms
All other outputs 75 Ohms (unbalanced), 150 Ohms (balanced)
Equivalent Input Noise, MIC input, A-weighted, 150 ohms -130 dBu
Noise, Channel inputs to Master A L/R outputs, A-weighted
Master fader down -100 dBu
Master fader 0 dB, Channel fader down -92 dBu
Master fader 0 dB, Channel fader 0 dB, Channel gain unity -82 dBu
Equalization
LO Shelving
±15 dB / 60 Hz
MID Peaking
±12 dB / 2.4 kHz
HI Shelving
±15 dB / 12 kHz
Master EQ 9-band
(63, 125, 250, 500, 1k, 2k, 4k, 6.3k, 12k Hz)
±10 dB / Q = 1.5 to 2.5
Filter
LO-CUT, mono inputs f = 80 Hz, 18 dB/oct.
Display 128 x 64 pixels, OLED
Effects
Type Dual stereo 24/48-bit multi effects processors
Effects presets 100 Factory + 20 User, Tap-Delay
Remote control Footswitch, MIDI
Digital Audio Interface
Channels 4 In / 4 Out
