Dynacord LX 1600 User Manual

11
MAINS OPERATION & RESULTING
LX3000
U
mains
[V]
I
mains
[A]
P
mains
[W]
P
out
[W]
Pd
(5)
[W]
BTU/hr
(1)
idle 230 1.3 145 - 145 495
Max. Output Power @ 8Ω
(1)
230 15.7 2500 2 x 900 700 2388
Max. Output Power @ 4Ω
(1)
230 26.0 4400 2 x 1500 1400 4777
1/3 Max. Output Power @ 4Ω
(1)
230 14.7 2320 2 x 500 1320 4504
1/8 Max. Output Power @ 4Ω
(1)
230 6.9 990 2 x 188 615 2098
1/8 Max. Output Power @ 4Ω
(2)
230 7.3 1070 2 x 188 695 2371
1/8 Max. Output Power @ 4Ω
(2),(4)
253 7.7 1200 2 x 227 746 2546
Normal Mode (-10dB) @ 4Ω
(1)
230 6.3 896 2 x 150 595 2030
Rated Output Power (0dB) @ 4Ω
(1)
230 23.5 3900 2 x 1200 1500 5118
Alert (Alarm) Mode (-3dB) @ 4Ω
(1)
230 16.4 2630 2 x 600 1430 4879
Max. Output Power @ 2Ω
(1)
230 40.7 7200 2 x 2100 3000 10236
1/8 Max. Output Power @ 2Ω
(1)
230 10.3 1525 2 x 263 1000 3412
1/8 Max. Output Power @ 2Ω
(2)
230 10.4 1535 2 x 263 1010 3446
(
1) Sine Modulation (1kHz) (2) Pink-Noise according EN60065 (3) 1BTU = 1055.06J = 1055.06Ws
(4) 10% Mains Over Voltage (5) Pd = Leakage Power
The following factors allow direct proportional calculation of the mains current Imain for different mains
supply voltages:
100V = 2.3; 120V = 1.9; 220V = 1.05; 240V = 0.96
