6.5.10.2 Pin 3/11 Function
Parameter Possible Values Default HHP Lite Std Adv
Pin 3 Function
None
Brake Light
Reverse Light
Beeper
Status
Power Status
Beeper
✓ ✓
Pin 11 Function Power Status
✓ ✓
These parameters set the function of Pin 3 and pin 11 on the tiller connector. Pin 3 and pin
11 are both capable of sinking 500 mA. To use the outputs, connect a 24 V beeper, lamp, or
Status LED (with resistor) between B+ and pin 3 or pin 11.
None — The output is not used.
Brake Light — The output pin drives a 24 V brake light. The brake light is on when the
scooter decelerates in either the forward or reverse direction. Connect the light between B+
and the pin that has 'Brake Light' selected.
Reverse Light — The output pin drives a 24 V reverse light. The reverse light is switched on
when the scooter drives in reverse. Connect the light between B+ and the pin that has
'Reverse Light' selected.
Beeper — The output pin drives a 24 V beeper. Connect the beeper between B+ and the pin
that has 'Beeper' selected. To activate any beeper sounds,set Enable Beeper to 'Yes'. Other
beeper options can be selected with Flash Code Beeper, Sleep Beeper, Motion Beeper, Deep
Discharge Beeper, Reversing Beeper, and Beeper Timing.
Status — The output pin drives a Status light. The Status light is on when the power is on.
When a fault condition exists, the Status light shows the related flash code.
Power Status — The output pin drives a Power-on light. The Power-on light is on when the
power is on. The Power-on light does not show flash codes, it remains on continuously.
If an output is set to 'Brake Light', 'Reverse Light', 'Status' or 'Power Status', the light used
can be a 24 V LED array (max. 500 mA) or a relay-driven incandescent or halogen bulb. If a
relay is used, a fly-back diode and a series diode must be installed. If an LED array is used,
it must have its own internal current limiting system. An LED array must also have reverse
polarity protection such as a series diode. An LED array may show a faint glow if the output
is not active. If this is the case, resistors mounted in parallel to the LED array may reduce
the glow.
For more information and schematics, see 5.9.10 Status Indicator Output, 5.9.11 Beeper
Output and 5.9.13 Brake and Reversing Lights.
