8.10.2 Motor / battery connector label (160 A and 180 A modules only)
Figure 69: Motor / battery connector label
Key
1 — Battery connections 3 — Torque specification
2 — Motor connections 4 — Dynamic Controls logo
8.10.3 Version label
Figure 70: Version label
Key
1 — Module 3 — Serial number
2 — Firmware version
The information contained on the version label is "as shipped from factory". Any
maintenance of the version label following a firmware upgrade by a third party is the
responsibility of that third party.
GBK51948 RHINO2
Installation Manual Issue 5
Appendices - Page 153
