Dynamic RHINO2 DS120 User Manual

6.3 Parameter List
Key: ✓ Editable at this level (✓ * = HHP Technician Mode)
Note
Some of the parameters in this list have a limited settable resolution; if a parameter value is set by an amount
that is smaller than the parameter’s step-size, the parameter’s value will be rounded to a value as close as
possible to the set value.
Parameter Possible Values Default HHP Lite Std Adv
User Personalisation (6.5.1 User Personalisation)
Sleep Timer 0 - 30min 30min
✓ ✓
Wakeup Style
Key + Throttle
Key Only
Key Only
✓
Swap Throttle
Direction
No / Yes No
✓ ✓ ✓ ✓
Enable Beeper No / Yes Yes
✓ ✓ ✓ ✓
Flash Code Beeper No / Yes No
✓ ✓ ✓ ✓
Sleep Beeper No / Yes Yes
✓ ✓ ✓ ✓
Motion Beeper
None
Reverse
Forward/Reverse
Reverse
✓ ✓ ✓ ✓
Reversing Beeper No/Yes No
✓
Beeper On Time 100 – 1500ms 300ms
✓ ✓ ✓
Beeper Off Time 0 – 1500ms 700ms
✓ ✓ ✓
Deep Discharge Beeper No / Yes Yes
✓ ✓ ✓
Sleep on Fault No / Yes Yes
✓ ✓ ✓
Power Off after Sleep No / Yes Yes
✓ ✓ ✓
Throttle Configuration (6.5.2 Throttle Configuration)
Throttle Type
Wig-wag
Single-ended
Uni-polar
Wig-wag
✓ ✓
Throttle Input
Single
Dual
Single
✓ ✓
Throttle Neutral Offset -0.6 +0.62 V 0 V
✓ ✓
Throttle Full Scale
Deflection
20 - 100 % 75 %
✓ ✓
Throttle Response 0 - 100 % 80 %
✓ ✓ ✓
Throttle Dead-band 0 - 100 % 25 %
✓ ✓
Throttle Testing No / Yes Yes
✓
Maximum Throttle
Voltage
0 - 5 V 4.90 V
✓
Minimum Throttle
Voltage
0 - 5 V 0.10 V
✓
Throttle OONAPU
None
Non-Latching
Latching
✓
GBK51948 RHINO2
Installation Manual Issue 5
Programming - Page 65
