Dynapac CP2100 - Technical Specifications -Dimensions

Technical specifications
10 4812325555EN 2018-02-08
Technical specifications -Dimensions
Dimensions
Dimensions
mm
inches
A – Between axles
4.000
157
B – Total width
2.032
80
H
1
– Height with attachment
3.344
132
H
2
– Total height
2.990
118
K – Height from the ground
250
9,8
L – Total length
5.180
204
A
L
H
2
H
1
B
K
