Instrument/controls - Description and function
2018-02-08 4812325555EN 21
Instrument/controls - Description and function
(cont.)
No.
DESIGNATION
SYMBOL
FUNCTION
13
"-" decrease of the sprinkler
interval (timer)
The sprinkling frequency decreases each
time the water volume on the wheels is also
decreased.
14
Working lights
Press to turn on/off all the working lights.
15
Horn switch
Press to sound the horn.
16
Emergency stop button
Press it to turn off the machine and the
engine. All the power supply is also turned
off.
17
Eco-mode
When activated, maintain speed reducing
the engine rotation, thus saving fuel (up to
30% economy)
18
Button to enable the
regeneration (Tier IV Engine)
Press to execute the regeneration
19
Button to disable the
regeneration (Tier IV Engine)
Press to disable regeneration.
20
Hazard warning lights
Press the switch to activate the hazard
warning lights.
21
Rotating beacon
Press the switch to activate the rotating
beacon.
