Dynapac CP2100 - Ground pressure (driving)

Operation
48 4812325555EN 2018-02-08
Ground pressure (driving)
The tire contact surface can be changed by means of tire
pressure.
The high pressure on the tires provides a smaller contact
surface (1) and the low pressure on the tire provides a larger
contact surface (2).
The contact surface with the ground is very important for the
compaction result. The total weight divided by the quantity of
tires provides the correct pressure for the wheel, according to
the following table.
Ground pressure
CP2100
CP2100W
Tire
TIRE PRESSURE (kPa)
Tire
TIRE PRESSURE (kPa)
11/20-18
240
350
480
620
720
830
14/70-20
240
350
480
620
720
830
LOAD ON
THE WHEEL
(kgf)
GROUND PRESSURE (kPa)
LOAD ON
THE WHEEL
(kgf)
GROUND PRESSURE (kPa)
1.125
200
240
270
300
330
340
1.125
163
181
188
228
261
290
1.375
220
260
300
330
350
380
1.375
175
193
199
240
276
308
1.825
240
280
340
380
400
430
1.825
194
212
219
261
301
339
2.250
250
310
360
410
440
480
2.250
211
229
236
280
326
370
2.750
260
320
390
440
480
520
2.750
231
248
256
303
356
408
3.000
270
330
410
460
490
540
3.000
242
257
267
315
373
430
Tire
TIRE PRESSURE (psi)
Tire
TIRE PRESSURE (psi)
11/20-18
35
50
70
90
105
120
14/70-20
35
50
70
90
105
120
LOAD ON
THE WHEEL
(lbs)
GROUND PRESSURE (psi)
LOAD ON
THE WHEEL
(lbs)
GROUND PRESSURE (psi)
2.500
29
35
39
44
47
49
2.500
24
26
27
33
38
42
3.000
31
38
44
48
51
55
3.000
25
28
29
35
40
45
4.000
35
41
49
55
58
62
4.000
28
31
32
38
44
49
5.000
37
45
52
60
64
69
5.000
31
33
34
41
47
54
6.000
38
47
57
62
70
75
6.000
34
36
37
44
52
59
6.500
39
48
59
66
71
78
6.600
35
37
39
46
54
62
Fig. - Ground contact surface
1. Contact surface with the tire (high pressure)
2. Contact surface with the tire (low pressure)
