Dynapac CP2100 - Page 96

Maintenance - Every 1,000 hours
92 4812325555EN 2018-02-08
Lubricate the upper/lower pivot bearing
1. Lubricate the grease fitting of the upper pivot bearing (1)
and the grease fitting of the lower pivot bearing (2)
operating the grease gun manually with five pump strokes.
2. Use the grease according to the lubricant specifications
recommended by DYNAPAC.
Lubricate the pivot bearing
1. Lubricate each grease fitting (1) with five hand-operated
strokes.
2. Use the grease according to the lubricant specifications
recommended by DYNAPAC.
1
Fig. - Rear cylinder
1. Grease fittings
1
2
Fig. - Pivot bearings
1. Upper pivot bearing grease fitting
2. Lower pivot bearing grease fitting
