11LF90 ILF090EN2
TECHNICAL DATA
The following sound and vibration levels are determined in accordance with the operating cycle
described by EU directive 2000/14/EC.
Guaranteed acoustic power level
L
wA
dB (A) 102 104
Sound-pressure level at the operator’s ear (ISO 6396)
L
pA
dB (A) 91 90
Hand and arm vibration (ISO 5349-1)
a
hv
m/s
2
, Standard handle 10,6 7,6
a
hv
m/s
2
, Vibration-damped handle 2,2 4,6
During operation these values may differ because of the actual operational conditions.
LF 90 LF 90
Honda Hatz
Weight
Net weight, kg (lbs) 98 (216) 111 (245)
Operating weight EN500, kg (lbs) 100 (221) 113 (249)
Compaction data
Vibr. frequency, Hz 83 83
Vibr. frequency, vpm 4980 4980
Centrifugal force, kN (lbf) 14 (3150) 14 (3150)
Amplitude, mm (in) 1,0 (0.039) 1,0 (0.039)
Operating data
Speed of travel, m/min (feet/min) 25 (82) 25 (82)
Max. tilt, ° 20 20
Volumes
Fuel tank, lit. (qts) 3,6 (3.8) 3,6 (3.8)
Crank case, lit. (qts) 0,6 (0.6) 0,6 (0.6)
Fuel consumtion, l/h (qts/h) 1,73 (1.83) 0,94 (99.4)
Engine
Model Honda Hatz
GX160 1B20
4-stroke Diesel
Recoil start Recoil start
Output, kW (hp) 4,1 (5.5) 2,5 (3.4)
Engine speed, rpm 3600 2600
Noise and Vibrations
