Dynapac LF90 - Maintenance - Every 100 Hours; 100-Hour Engine Oil Change; 100-Hour V-Belt Inspection; 100-Hour Fuel System Check

20
LF90 ILF090EN2
MAINTENANCE – EVERY 100 HOURS OF OPERATION
1. Change oil (first change after 20 hours, together with
engine oil filter).
Use the accompanying hose to drain the oil.
Save the oil and dispose of it in an approved
manner.
1. Oil dipstick
2. Oil filter
3. Oil drain plug/drain hose
1
3
1
2
Hatz 1B20
3
1. Take off the protective cover and inspect the V belt.
2. To adjust belt tension, loosen the four engine-plate
bolts and slide it into position.
3. Tighten the bolts and replace the protective cover.
Never run the machine without the protec-
tive cover over the V belt.
L000128A
L000252A
L000253A
1. Check and clean the fuel filter and the fuel tank.
1. Fuel tank
2. Fuel filter
1
2
1
Hatz 1B20
L000252A
L000253A
Honda
GX160
Honda
GX160
