Dynapac LF90 - Operation - Hatz 1 B20 Engine; Hatz Engine Pre-Start Checks; Starting and Stopping the Hatz Engine

13LF90 ILF090EN2
Before start
2
1
1. Check the oil level in the engine.
2. Fill the fuel tank with fuel.
3. Check that all operating controls are working.
Starting the engine
4. Open the fuel cock.
5. Move the throttle lever to START position.
6. Pull the starting cable out by the handle until you feel
a slight resistance. Let the cable run back; in this
way the entire length of the starting cable can be
used to start the engine.
If after several attempts of starting the exhaust
begins to emit white smoke, move the speed
control lever to the stop position and pull the
starting cable out slowly 5 times. Repeat the
starting procedure.
Stopping the engine
1. Move the throttle lever down to STOP position.
OPERATION – HATZ 1B20
L000241AL000077A
6
L000610A
L000246A
4
L000242A
5
L000611A
1
