13
LH 300/700 ILH300EN4
HANDLE POSITION
LH 300
LH 700
L000426A
L000427
L000437
L000428
1. Working/Extra power positions:
The handle has two operating positions. The
normal working position is with the locking device
unlocked, so the handle can move freely. The
extra power position, with the locking device in
the lower locked position, is used to get power
and control on wet and very soft materials.
Hold the handle while releasing the catch.
There are two catches, one on each side of
the handle.
1. Working/transport positions:
The handle has two positions. When operating
the machine, press the locking device lever and
pull the handle down to the lower position. When
transporting the machine, raise the handle and
push it to locked position.
Hold the handle while releasing the catch.
Extra power position
Transport position
2. Transport position:
When transporting the machine, turn and lift the
locking device and raise the handle to the upper
position. Always lock the handle when transpor-
ting the machine.
Working position
Working position
WARNING
WARNING
